Product Details:
Payment & Shipping Terms:
|
| Product: | SDL Screw Type Feeder | Application: | Feeding Concrete Cement And Sand |
|---|---|---|---|
| Power Type: | Electric Motor /diesel Engine | After-sales Service: | Technical Online Supports Through Video |
| High Light: | SDL Screw Feeder,Aggregate Batching belt Screw Feeder,belt Screw Feeder For Grain |
||
1. Compact structure, light weight, high performance.
2. Electric or diesel engine driven, suitable for different working environment.
SDL Screw Type Feeder Application:
1. Conveying cement, mortar, concrete etc. The feeder can be equipped with shotcrete machine in tunnel, culvert, highway slope, subway, underground works and mine laneway etc.
2. Conveying grains, corns, fertilizers etc. in agricultural industry.
| Model | Screw diameter (Screw feeder) mm | Belt width (Belt feeder) mm | Rated input power kw | Length m |
| SDL160 | 150-180(length can be customized) | 3(4/5.5) | 2/3 | |
| SDL220 | 200-230(length can be customized) | 5.5(4/7.5) | 2/3/4 | |
| SDL300 | 300-330(length can be customized) | 300(length can be customized) | 4(5.5/7.5/11) | 3/4/5 |
| SDL400 | 400-430(length can be customized) | 400(length can be customized) | 4(5.5/7.5/11) | 3/4/5 |
| SDL600 | 600-630(length can be customized) | 600(length can be customized) | 5.5(7.5/11) | 3/4/5/6 |
| SDL800 | 800-830(length can be customized) | 7.5(11) | 4/5/6/9 | |
| SDL1000 | 1000-1030 | 11(15) | 5/6/9 |
