Product Details:
Payment & Shipping Terms:
|
| Product Name: | KEMING Brand Drilling Rig | Advantage: | Excellent Performance |
|---|---|---|---|
| Rock Hardness: | F=6-20 | After-sales Service: | Online Video Service |
| High Light: | KEMING Brand Drilling Rig,Drilling Rig With Low Center |
||
1. High efficiency simplem
2. Drilling rigs are a new, highly efficient and extensively applied open-air rock drilling equipment designed by our company, which is extensively suitable for small and medium sized mines and the projects such as communications, national defense, water conservancy and stonework, in particular the rough and rugged terrains and land forms where other drills are unable to operate normally.
| Model | KQD70 | KQD100A | KQF100 | KQJ100A electric | KQJ100A diesel | |
| Rock hardness | F=6-20 | F=6-20 | F=6-20 | F=6-20 | F=6-20 | |
| Borehole Diameter | mm | 50-80 | 68-130 | 68-130 | 68-130 | 68-130 |
| Borehole Depth | m | ≥15 | ≥20 | ≥20 | ≥20 | ≥20 |
| One-time advance length | mm | 1000 | 1000 | 1000 | 1000 | 1000 |
| Swing speed | r/min | 90 | 90 | 110-160 | 0-70 | 0-70 |
| Air consumption | m3/min | ≥3.5 | ≥7 | ≥12 | ≥7 | ≥7 |
| Working air pressure | Mpa | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 |
| Cylinder diameter | mm | 90 | 140 | 140 | 50 | 50 |
| Max. lifting force | N | 4200 | 7000 | 7000 | 15000 | 15000 |
| Max. advance force | N | 3500 | 5000 | 5000 | 4500 | 4500 |
| Whole weight | kg | 175 | 260 | 260 | 260 | 260 |
| Driving power | kw | 3 | 4 | 4 | 7.5 | 12.1 |
KEMING Brand Drilling Rig Application:
1. High efficiency simplem
2. Drilling rigs are a new, highly efficient and extensively applied open-air rock drilling equipment designed by our company, which is extensively suitable for small and medium sized mines and the projects such as communications, national defense, water conservancy and stonework, in particular the rough and rugged terrains and land forms where other drills are unable to operate normally.
FAQ
1. Q: Can we have customized model?
A: Yes. Customized production and OEM production are available according to your actual requirements.
2. Q: What should we do if there are some problems with the machine?
A: The Operate Instruction will help with routine maintenance and common problems.
Also, you can contact us for technical instruction by email, instant messenger or live video etc.
3. Q :How to pay for this order?
A: Generally, TT, 30% deposit 70% before shipment;
L/C at sight (high bank charge, not suggest, but acceptable);
100% TT in advance (especially for small amount and spare parts etc.)
