Underground Mining Robotic Shotcrete Machine For Tunnel

Underground Mining Robotic Shotcrete Machine For Tunnel

  • High Light

    Mining Robotic Shotcrete Machine

    ,

    Underground Robotic Shotcrete Machine

    ,

    Tunnel Robotic Shotcrete Machine

  • Capacity
    5~15m3/h
  • Spraying Hose
    51mm. 57mm. 64mm
  • Max Spraying Height
    8m
  • Max Spraying Width
    11m
  • Place of Origin
    CHINA
  • Brand Name
    KEMING
  • Certification
    CE,MA
  • Model Number
    KPC-80
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiation
  • Packaging Details
    Export Wooden Case
  • Delivery Time
    5~10 Work Day
  • Payment Terms
    L/C, T/T
  • Supply Ability
    100 Set/Per Month

Underground Mining Robotic Shotcrete Machine For Tunnel

Underground Mining Concrete Spraying Shotcrete Robot For Tunnel Machine

Shotcrete Machine Features:

1. KPC-80 Shotcrete robot is suitable for spraying dry concrete, wet concrete or wet and dry mixture.

2. It adopts independent hydraulic drive and 4 hydraulic legs, which greatly improves the stability of the equipment during the spray process.

3. It adopts explosion-proof electrical design, which makes it acceptable in underground coal mine.

4, It is equipped with unique protective cover, which can protect the robot arm.

Shotcrete Machine Application:

1. KPC-80 Shotcrete robot is an ideal equipment for any working space, even in narrow tunnel construction.

2. It is widely applied in mining well, railway, hydropower station, urban construction and other engineering constructions.

3. It can be used for slope stability (slope stability), excavation and support, shotcrete support of small vertical shaft in tunnel, coal mine or power station construction.

Shotcrete Machine Parameters:

Parameter
Dimensions in transport mode (L*W*H)
4500*1080*2200 mm
Weight
3000 kg
Maximum length of operation
8400 mm
Outrigger expansion width
2500 mm
Boom parameters
Maximum spraying height
8.2m
Maximum spraying width
11m
Hose ID
51mm/57mm/64mm
Boom frame telescopic distance
2.7m
Boom expansion maximum length
6m
Chassis
Maximum gradient of walking
25 %
Ground slope of working
2%
Walking speed
0.5km/h
Ground clearance
390 mm
Power
Motor output of Hydraulic system
11 kW
Voltage
660~1140V, 50Hz
