Product Details:
Payment & Shipping Terms:
|
| Product: | KEMING Cement Hollow Block Making Machine | Capacity: | 10-40 M3/h |
|---|---|---|---|
| Max. Output Pressure: | 5 MPa | Maintencance: | Online Video Support |
| High Light: | Saving Cement Foaming Machine,5 MPa Hollow Block Machine,foaming system Hollow Block making Machine |
||
1. KEMING Hollow Block Making Machine combines feeding machine, water adding device, mixing system, foaming system, delivery system together. It is convenient to operate, automatic cement feeding, automatic mixing of cement slurry, automatic foaming of foaming agent, automatic delivery of foaming concrete.
2. The machine adopts high pressure foaming technology with good foaming performance,even,high quality,unbreakable,accurate(foaming amount can be precisely controlled within mg).
3. Delivery system adopts the most advanced pumping system of hose pump, with simple operation, low fault rate, less wearable parts, convenient maintenance,and low cost.
4. The machine shell is made of high strength and precious steel plate,which is painted at high temperature of 280℃ and has long service life.
5. The machine saves production costs and improves economical returns.Compared with similar products, the machine can save 50~100kg cement per cubic meter product.
6. The machine is the ideal equipment of foaming cement,with light weight,small size, convenient movement, high efficiency.
1. KEMING Hollow Block Making Machine is widely used to produce lightweight cement, thermal insulation materials, heat preservation materials, and water proof materials etc.
2. Take cement and coal ash as raw material to make foam concrete.
3. Insulating layer, bedding course, floor heating, filling projects of foam concrete roofing.
4. Other products of foam concrete.
|
Model |
Capacity m3/h |
Pressure Mpa |
Power KW |
Delivery distance m |
| KFP50 | 1-8 | 3,1.5 |
5.5 |
100/50 |
| KFP70 | 1-10 | 3,1.5 |
7.5 |
200/70 |
| KFP100 | 1-15 | 3,1.5 |
7.5 |
300/100 |
| KFP-65-20A | 10-12 | 1.5 |
7.5 |
100/20 |
| KFP-65-40A | 10-12 | 1.5,3 |
7.5 |
200/40 |
| KFP-76-20A | 18-20 | 1.5 |
11 |
100/20 |
| KFP-76-40A | 18-20 | 1.5,4 |
11 |
200/40 |
| KFP120 | 1-25 | 3,1.5 |
11 |
300/120 |
| KFP150 | 1-30 | 4,2 |
11 |
300/120 |
| KFP-90-20A | 38-40 | 1.5 |
15 |
100/20 |
| KFP-90-40A | 38-40 | 1.5,5 |
15 |
200/40 |
| KFP180 | 1-40 | 5,2 |
15 |
100/20 |
| KFP200 | 1-50 | 5,2.5 |
15 |
100/20 |
As a comprehensive high-tech enterprise, Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. is engaged in the research and production of mining machinery, engineering machinery and supporting equipment for underground engineering, as well as environment protection, chemical industry, inspection and testing of mining equipment, research and production of mechanical and electrical products, technology and finance, management and technology consulting service, and other industries.
Our company has obtained more than 20 national invention patents and utility model patents, more than 10 scientific and technological achievements appraisal awards, 8 awards from China National Coal Association and Department of science and technology of Henan province, and the second prize of Henan Provincial S&T Progress Award.
In 2014, the brand “KEMING” was awarded the “Henan Provincial Famous Trademark”. In 2018, our company was awarded ISO9001 Quality Management System Certification, OHSAS 18001 Occupational Health and Safety Management System Certification, ISO14001 Environmental Management System Certification and CE Certification.
