Product Details:
Payment & Shipping Terms:
|
| Product Name: | 2ZBQ-20/4 Pneumatic Grout Pump | Drive: | Pneumatic Motor |
|---|---|---|---|
| Weight: | 150kg | After-sales Service Provided: | Online Support |
| High Light: | Pneumatic Grout Pump For Rock Consolidation,large Output Capacity Pneumatic Grout Pump,Pneumatic Grout Pump For Coal Mine |
||
Pneumatic Grout Pump uses compressed air for pressure signal transmition.
1. Advanced structure, high output pressure, large output capacity, high efficiency.
2. The pump adopts compressed air to transmit pressure signal, which forms close automatic control system to ensure reliable performance.
3. Reversing mechanism has automatic positioning function by air pressure with no "self-stop" phenomenon.
4. Pneumatic transmission, strong anti-pollution ability, small size, light weight, easy movement.
1. The pump has single or double liquid grouting function.
2. It can work in inflammable, explosive, strong rediative, dusty sites and other bad environments with changeable temperature.
3. Slope protection grouting in civil engineering, mining tunnel construction etc.
4. KBY Hydraulic Grout Pump is mainly applied in mining well, tunnel, hydraulic engineering subway, bridge and building construction, to grout for water blocking, fill in void or reinforce the crumbly strata.
| Items | Parameters | |
| 2ZBQ-10/3 | ZBQ-25/2 | |
| Pressure(Mpa) | 0-3 | 0-5.5 |
| Output(L/min) | 0-14 | 0-30 |
| Working aire pressure(Mpa) | 0.2-0.63 | |
| Inlet dia. (mm) | 25 | 38 |
| Outlet dia.(mm) | 13 | 19 |
| Items | Parameters | ||||
| 2ZBQ-20/4 | 2ZBQ-10/10 | 2ZBQ-70/7 | 2ZBQ-30/30 | 2ZBQ-50/19 | |
| Output pressure Mpa | 4 | 10 | 7 | 30 | 19 |
| Output capacity L/min | 20 | 10 | 70 | 30 | 50 |
| Working air pressure Mpa | 0.2-0.63 | ||||
|
Outlet dia. mm |
25 | ||||
| Inlet dia. mm | 13 | 19 | |||
