Product Details:
Payment & Shipping Terms:
|
| Product Name: | Hydraulic Grout Pump | Driven Mode: | Electric Motor, Diesel Engine |
|---|---|---|---|
| Motor Power: | 11-30kw | Keyword: | Cement Mortar Pump |
| After-sales Service Provided: | Video Technical Support | ||
| High Light: | Hydraulic Grout Pump For Tunnel,Diesel Engine Hydraulic Grout Pump,Single Fluid Grouting Hydraulic Grout Pump |
||
1. Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. (the former Keming Mechanical and Electrical Department of Henan Coal Scientific Research Institute) is a holding subsidiary of Henan Coal Scientific Research Institute Co., Ltd. Our company is dedicated to the research and development, production and sales of shotcrete machine, grouting pump, and complementary products.
2. Hydraulic Grout Pump includes KBY series and KBYSseries, which are a kind of grounting pump that can grount and convey mortar or similar fluids materials.
1. Adjustable grounting pressure within the rated pressure.
2. Perfect waterproof device.
3. Separated control valves.
4. Single or double fluid grounting.
1. KBY Hydraulic Grout Pump is mainly applied in mining well, tunnel, hydraulic engineering subway, bridge and building construction, to grout for water blocking, fill in void or reinforce the crumbly strata.
2. KBYS hydraulic mortar pump can be used for horizontal and vertical mortar delivering or large are a coating in construction engineering.
3.Filling cement grouting of road surface collapese in highway payment maintenance.
4. Dam reinforcement in water engineering.
5.Slurry injection expansion in pre-stressed engineering.
6. Slope protection grouting in civil engineering, mining tunnel construction etc.
| Model | Pressure Mpa | Output m3/h | Motor kw | Weight kg |
| KBY3/7-11 | 0 | 4.6 | 11 | 400 |
| 7 | 3 | |||
| KBY8/7-18.5 | 0 | 13 | 18.5 | 600 |
| 7 | 2 | |||
| KBY3/16-22 | 0 | 10.2 | 22 | 480 |
| 16 | 2 | |||
| KBY2.1/21-22 | 0 | 2.7 | 22 | 480 |
| 21 | 0.6 | |||
| KBY5/18-22 | 0 | 5.2 | 22 | 480 |
| 18 | 1.2 | |||
| KBY3/21-30 | 0 | 4.9 | 30 | 510 |
| 21 | 3 |
