Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station

  • High Light

    Stucco Plastering Mortar Spraying Machine

    ,

    Mortar Spraying Machine 4kw

    ,

    Hydropower Station Mortar Spraying Machine

  • Warranty
    12 Month
  • After-sales Service Provided
    Operate Instruction
  • Condition
    New
  • Power(w)
    4kw
  • Application
    Stucco Plastering
  • Voltage
    Customized
  • Color
    Customized
  • Name
    Stucco Plaster
  • Place of Origin
    Zhengzhou
  • Brand Name
    KeMing
  • Certification
    CE, MA, ISO
  • Model Number
    KLW series
  • Minimum Order Quantity
    1 set
  • Packaging Details
    wooden box
  • Delivery Time
    2-3 weeks
  • Payment Terms
    T/T, Western Union, D/P, D/A, L/C
  • Supply Ability
    20 sets per month

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station

KLW -120 Diesel Mortar Spraying Machine Stucco Plaster Warehouse Repair



Application:

1. KLW-120 Diesel Plastering Machine is a multi-functional plastering equipment, widely used for pumping and spraying ready-mixed materials.
2. Engineering grouting: pressure grouting for reservoir, hydropower station, dam, port, wharf; reinforcement grouting for soft foundation; backfill grouting or rock bolting for tunnel, subway, mining well etc.
3. Slurry circulation or mortar backfill in deep mine construction of ground source heat pump.
4. Mortar delivery for weighbridge, masonry and plastering. Mortar delivery and plastering of commercial mortar or other mortar with equivalent performance.



The mortar spraying machine is simple to operate, no scaffolding, no moving equipment, no repair and stubble, both the male and female corners and the roof can be sprayed freely, which shortens the construction period, improves the progress, and saves the expenditure of the frame material.



Features:

1. KLW-120 Diesel Plastering Machine is a screw type wet plastering equipment.
2. KLW -120 Diesel
 Plastering Machine is composed of a screw pump and air compressor.
3. KLW -120 Diesel
Plastering Machine has small size and light weight, flexible movement, convenient operation and maintenance.
4. Low noise, high pressure, high capacity, high efficiency, reliable performance, long service life.



Specification:

model spraying distance capacity power aggregate size pressure air consumption hopper volume dimension
KLW-120 10m/15m 110-120 m2/h(mortar)200-300 m2/h(putty)3m3/h (grouting) 4 kw 4mm 2MPa 2.2 kw 0.26m3/min 35L 1300x650x900mm
KLW-120D 10m/15m 120-130 m2/h 12hp 4mm 2MPa 0.26m3/min 35L 1800x850x1300mm
KLW-150 15m/25m 120-150 m2/h 7.5 kw 5mm 3MPa 2.2 kw 0.36m3/min 50L 2150x730x1100mm
KLW-150D 15m/25m 150-160 m2/h 15hp 5mm 3MPa 0.4m3/min 50L 2050x950x1300mm
KLW-180 20m/50m 150-180 m2/h 7.5 kw 6mm 3MPa 2.2 kw 0.4m3/min 50L 2350x750x700mm
KLW180J with mixer 20m/50m 150-180 m2/h 7.5 kw 3kw 6mm 3MPa 2.2 kw 0.4m3/min 60L 2350x750x1300mm

Certification:

In July 2009, the company passed the ISO9001:2008 Quality Management System Certification. In October 2010, the company was entitled as the “Henan Provincial High-tech Enterprise”.
In 2013, the new wet shotcrete technology was reward the second prize of
Henan Provincial S&T Progress Award.

In December 2014, the brand “KEMING” was awarded the “Henan Provincial Famous Trademark”.
In October 2016, “KEMING” series products have been certified by CE Certification.

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 0Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 1Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 2

Related machines:

Our main machines are : Shotcrete equipment, grouting equipment, mixing equipment, plastering equipment, hose pump etc.

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 3

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 4

Why choose us:

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 5



Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. (the former Keming Mechanical and Electrical Department of Henan Coal Scientific Research Institute) is a holding subsidiary of Henan Coal Scientific Research Institute Co., Ltd.

Our company is dedicated to the research and development, production and sales of shotcrete machine, grouting pump, and complementary products. Up to now, we have developed more than 50 kinds of products, covering spraying machines, pumps and other series of products.

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 6Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 7

Achievements: Our company has obtained more than 20 national invention patents and utility model patents, more than 10 scientific and technological achievements appraisal awards, 8 awards from China National Coal Association and Department of science and technology of Henan province, and the second prize of Henan Provincial S&T Progress Award.
Business Scope: As a comprehensive high-tech enterprise, our company is engaged in the research and production of mining machinery, engineering machinery and supporting equipment for underground engineering, as well as environment protection, chemical industry, inspection and testing of mining equipment, research and production of mechanical and electrical products, technology and finance, management and technology consulting service, and other industries.



Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 8Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 9

Cooperate Culture:

Enterprise Spirit: Devotion, responsibility, innovation, excellence
Service Concept: Serve consumers and satisfy consumers
Business Philosophy: Cultivate excellent talent, invent superior product, offer perfect service
Enterprise Vision: Lead the machinery manufacturing industry, be an outstanding listed company
Corporate responsibility: Be responsible for the society, operate lawfully, contribute to the society
Be responsible for the shareholder, increase the assets value, stabilize the returns
Be responsible for the customer, service-oriented, integrity-based
Be responsible for the staff, make career plan, live and work in peace

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 10

Exhibition:

Bauma Shanghai 2018

Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 11Stucco Plastering Diesel Mortar Spraying Machine 4kw For Hydropower Station 12

FAQ:

1. Q:How to pay for this order?

A:Generally, TT, 30% deposit 70% before shipment; L/C at sight (high bank charge, not suggest, but acceptable);100% TT in advance (especially for small amount and spare parts etc.)
2. Q:How to place an order?
A:Both online order and offline order are acceptable.
3. Q:How about the package?
A:We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
4. Q:What is the lead time?
A:1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
5. Q:What should we do if there are some problems with the machine?
A:You can refer to the Operate Instruction or call our 24-hour service hotline. Also, our engineers are available to service overseas.
6. Q:Do i need technical skills to operate this machine?
A:Yes. Please read the Operation Instruction for some basic technical skills. And, we provide online and onsite technical training if necessary.
