Self Suction Resin Insulation Industrial Hose Pump

Self Suction Resin Insulation Industrial Hose Pump

  • High Light

    Resin Insulation Industrial Hose Pump

    ,

    300L/h Industrial Hose Pump

    ,

    Self Suction Peristaltic Hose Pump

  • Capacity
    210~300L/h
  • Pressure
    0.6Mpa
  • Motor
    0.55kW
  • Aggregate
    2mm
  • Place of Origin
    CHINA
  • Brand Name
    KEMING
  • Certification
    CE
  • Model Number
    KH15B
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiation
  • Packaging Details
    Export Wooden Packing
  • Delivery Time
    10~30 Work Days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    100 Sets/Per Month

Self Suction Resin Insulation Industrial Hose Pump

Small Flow Resin Insulation Pump Can Be Used In The Fire Industry

Peristaltic Hose Pump Features:

1. High vacuum, strong self-suction capacity.

2. No valve operation, no back flow, stable pumping flow, low fault rate.

3. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.

4. Convenient maintenance, less wearable parts (except extruded hose).

Peristaltic Hose Pump Application:

1. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.

2. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.

3. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.

4. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...

5. Oil industry: drilling fluid,crude oil.

6. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.

7. Paper industry: paper pulp, liquid sulfur.

8. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.

9. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.

10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Technical Parameters:

Model
KH15B Peristaltic Hose Pump
Output
210~300 L/h
Rated pressure
0.6 MPa
Rev.
45~75 r/min
Hose length
715 mm
Max. particle dia.
2 mm
Max. suction dist.
2 m
Motor power
0.55 KW
Reducer type
Cycloidal reducer
Note:
Driven power could be electric motor or diesel engine.
Various squeeze hoses are available for pumping different materials.
Customized pump is available.
