Cylinder Piston 50L/Min 4Mpa 10hp Mortar Grout Pump

Cylinder Piston 50L/Min 4Mpa 10hp Mortar Grout Pump

  • High Light

    10hp Mortar Grout Pump

    ,

    50L/Min Mortar Grout Pump

    ,

    Cylinder Piston Mud Grout Pumps

  • Capacity
    50L/min
  • Pressure
    4Mpa
  • Aggregate Size
    5mm
  • Diesel Engine
    10hp
  • Place of Origin
    CHINA
  • Brand Name
    KEMING
  • Certification
    CE
  • Model Number
    KHB-50D
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiation
  • Packaging Details
    Export Wooden Packing
  • Delivery Time
    5~8 Work Days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    100 Sets/Per Month

Cylinder Piston 50L/Min 4Mpa 10hp Mortar Grout Pump

Good Performance Used Mud Grout Pumps Grouting Injection Pump With Diesel Engine

Mortar Pump Features:

1. Horizontal single Cylinder Piston Grouting Pump.

2. Electricity, Diesel Driven or Unpowered Machine Optional.

3. Stable Output, High Pressure and Great Grout Injection Performance.

4. High Quality and Compact Structure, Easy to Install, Operate, Move and Maintain.



Mortar Pump Application:

1. KHB cement mortar pump is used for mortar delivery, fundamental grouting and mending, grout reinforcement of dam, bridge, culvert and tunnel, and delivery of slurry materials, magnetic materials, or other materials.

2. It can also be used for wall plastering equipped with spraying gun and compressed air.

3. It is widely applied in construction engineering, metallurgical industry, chemical industry, infrastructure construction, and national defense engineering etc.

Suggestion: Cement-sand ratio≥1:3.

Technical Parameters:

Model
KHB-50D Mortar Pump
Capacity
50L/min
Max. Pressure
4MPa (40bar, 580psi)
Cylinder Dia.
90mm
Piston Stroke
85mm
Piston Speed
95/min
Inlet Dia.
75mm
Outlet Dia.
50mm
Cement:sand
≥1:3
Max. aggregate size
5mm
Motor Power
10hp (diesel engine)
Weight
400kg
Dimensions (LxWxH)
1610x1024x900mm
