Waterproof Mortar 4kw 2Mpa Cement Plastering Machine

China Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. certification
China Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. certification
I'm Online Chat Now

Waterproof Mortar 4kw 2Mpa Cement Plastering Machine

Waterproof Mortar 4kw 2Mpa Cement Plastering Machine
Waterproof Mortar 4kw 2Mpa Cement Plastering Machine

Large Image :  Waterproof Mortar 4kw 2Mpa Cement Plastering Machine

Product Details:
Place of Origin: CHINA
Brand Name: KEMING
Certification: CE
Model Number: KLW120
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Export Wooden Case
Delivery Time: 10~15 work days
Payment Terms: T/T, L/C
Supply Ability: 100 Sets/Per Month
Detailed Product Description
Output: 110~120m2/h Pressure: 2Mpa
Max Aggregate: 4mm Spraying Distance: 15m/10m
Main Motor: 4kW Air Compressor: 0.26 M3/min
High Light:

2Mpa Cement Plastering Machine

,

4kw Cement Plastering Machine

New Putty Plaster Waterproof Material Cement Mortar Spraying Machine

Plastering Machine Application:

  • 1. KLW-120 mortar plastering machine is mainly used for building internal and external wall surface goods mixed mortar, putty powder, refractory coating and pressure grouting.Working principle of the cement or cement products similar to join the feeder,, good mixing slurry under the action of screw pump, is pressurized continuous discharge, and along the pipeline conveying forward, arrived at the nozzle is introduced into the wind, slurry under the action of wind, jet formation, and into the wall.
  • 2.On the surface.Highway, railway tunnel, urban subway, hydropower station underground caverns, such as grouting engineering, can be used in dam, slope, soft rock reinforcement soil grouting engineering, anchor grouting, unity
  • 3.Grouting and backfill grouting and grouting tabernacle modernization construction equipment of the construction site.

Plastering Machine Features:

  • 1. KLW-120 mortar plastering machine is a high-pressure screw type mortar plastering pump.
  • 2. Small size and light weight, flexible movement, convenient operation and maintenance.
  • 3. Low noise, high pressure, high capacity, high efficiency, reliable performance, long service life.



Plastering Machine Parameters:

Model
KLW-120 Plastering Machine
Capacity
100~120m2/h(mortar)
200~3002/h(putty)
3m3/h(grouting)
Motor power
4kW
Output pressure
2Mpa
Delivery dist.
15m/10m
Max. aggregate size
4mm
Water: cement:sand
0.7-1:1:3
Hopper volume
35L
Delivery pipe
32mm
Air hose
13mm
Air compressor
0.26m3/min
Weight
200kg



Waterproof Mortar 4kw 2Mpa Cement Plastering Machine 0
