Foam Concrete Block Peristaltic Industrial Hose Pump

Foam Concrete Block Peristaltic Industrial Hose Pump

  • High Light

    Peristaltic Industrial Hose Pump

    ,

    1.5Mpa Industrial Hose Pump

  • Capacity
    4.2~8m3/h
  • Pressure
    1.5Mpa
  • Motor
    4KW, 5.5KW, 7.5kW
  • Aggregate
    5mm
  • Place of Origin
    CHINA
  • Brand Name
    KEMING
  • Certification
    CE
  • Model Number
    KH50B
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiation
  • Packaging Details
    Export Wooden Packing
  • Delivery Time
    10~30 Work Days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    100 Sets/Per Month

Foam Concrete Block Peristaltic Industrial Hose Pump

Factory Industrial Hose Pump High Volume Rate Peristaltic Chemical Pump For Foam Concrete Block

Industry Hose Pump Features:

1.KH series industrial hose pump(squeeze pump)consists mainly of pump house, rotor, idle, squeeze tube and driving unit.

2. The squeeze hose is U-shape in pump house, when rotor drives roller to rotate, hose is deformed. After the roller rotate, the deformed hose recover by its elasticity. Thus the negative pressure in this hose is generated, sucking slurries, and discharging through outlet under roller's push, finally forms pressure conveying of slurries.

Industry Hose Pump Application:

1. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.

2. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.

3. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.

4. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...

5. Oil industry: drilling fluid,crude oil.

6. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.

7. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.

8. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.

9. Paper industry: paper pulp, liquid sulfur.

10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Technical Parameters:

Model
KH50B Peristaltic Pump
Output
4200~8000 L/h
Rated pressure
1.5 MPa
Rev.
35~45 r/min
Hose length
1360 mm
Max. particle dia.
5 mm
Max. suction dist.
5 m
Motor power
4/ 5.5/ 7.5 KW
Reducer type
Cycloidal reducer
Note:
Various squeeze hoses are available for pumping different materials.
Driven power could be electric motor or diesel engine.
Customized pump is available.
