1.5Mpa 4KW Concrete Hose Squeeze Peristaltic Pump

1.5Mpa 4KW Concrete Hose Squeeze Peristaltic Pump

  • High Light

    Squeeze Peristaltic Pump

    ,

    Peristaltic Concrete Hose Pump

  • Capacity
    2000~3500L/h
  • Pressure
    1.5Mpa
  • Motor
    2.2kW, 3KW, 4KW
  • Aggregate
    5mm
  • Place of Origin
    CHINA
  • Brand Name
    KEMING
  • Certification
    CE
  • Model Number
    KH38C
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiation
  • Packaging Details
    Export Wooden Packing
  • Delivery Time
    10~30 Work Days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    100 Sets/Per Month

1.5Mpa 4KW Concrete Hose Squeeze Peristaltic Pump

Concrete Hose Squeeze Peristaltic Pump For Industry Application

Peristaltic Pump Features:

1. Reversibility

2· Sealessness and valveless

3· Abrasion resistance

4· Self priming with high suction

Peristaltic Pump Application:

1. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.

2. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.

3. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.

4. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...

5. Paper industry: paper pulp, liquid sulfur.

6. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.

7. Oil industry: drilling fluid,crude oil.

8. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.

9. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.

10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Technical Parameters:

Model
KH38C Peristaltic Pump
Output
2000~3500 L/h
Rated pressure
1.5 MPa
Rev.
40~70 r/min
Hose length
1150 mm
Max. particle dia.
5 mm
Max. suction dist.
4 m
Motor power
2.2/ 3/ 4 KW
Reducer type
Gear reducer
Note:
Driven power could be electric motor or diesel engine.
Various squeeze hoses are available for pumping different materials.
Customized pump is available.
