Product Details:
Payment & Shipping Terms:
|
| Capacity: | 1.8~2.8m3/h | Pressure: | 1.0Mpa |
|---|---|---|---|
| Motor: | 11KW, 15kW | Aggregate: | 6mm |
| Highlight: | food grade liquid transfer pump,concrete foam transfer pump |
||
|
Model
|
Rated Output
m3/h
|
Rated pressure
MPa
|
Rated power
KW
|
Max. aggregate size
mm
|
Max. suction dist.
m
|
|
KH15
|
0.3
|
0.6
|
0.55
|
2
|
2
|
|
KH25
|
0.8~1.3
|
1.5
|
1.1/ 1.5
|
3
|
3
|
|
KH32
|
1.3~1.8
|
1.5
|
2.2
|
3
|
4
|
|
KH40
|
2.0~3.5
|
1.5
|
2.2/ 4
|
4
|
4
|
|
KH50
|
4.0~8.0
|
1.5
|
4/ 5.5/ 7.5
|
5
|
5
|
|
KH65
|
9.0~15.0
|
1.0
|
7.5/ 11
|
6
|
5
|
|
KH75
|
15.0~30.0
|
1.0
|
11/ 15
|
6
|
5
|
|
KH90
|
30.0~40.0
|
1.0
|
15/ 18
|
6/8(soft)
|
5
|
|
KH100
|
40.0~50.0
|
1.0
|
15/ 18
|
6/8(soft)
|
5
|
|
KH130
|
50.0~70.0
|
1.0
|
18/ 22
|
6/10(soft)
|
5
|
|
KH150
|
70.0~80.0
|
1.0
|
22/ 30
|
6/10(soft)
|
5
|
|
KH200
|
100.0~110.0
|
1.0
|
30/37
|
6/15(soft)
|
5
|
1. No valve operation, no back flow, stable pumping flow, low fault rate.
2. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.
3. High vacuum, strong self-suction capacity.
4. Convenient maintenance, less wearable parts (except extruded hose).
1. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.
2. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.
3. Architecture: mortar, plaster, cement paste, soil slurry, silt slurry, lime slurry, foamed concrete, architectural coating, refractory, accelerator, ooze, waste water, sewage and so on.
4. Oil industry: drilling fluid,crude oil.
5. eramic industry: ceramic germ plasma, slip glaze, glaze materials.
6. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...C
7. Paper industry: paper pulp, liquid sulfur.
8. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.
9. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.
10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.
