Product Details:
Payment & Shipping Terms:
|
| Model: | KH 15 | Warranty: | 1 Year |
|---|---|---|---|
| Color: | Customized | Capacity: | 0.3-80 M3/h |
| Max Aggregate Size: | 2-10mm | Power Engine: | Electric Driven |
| Name: | Hose Pump | Certificate: | CE, ISO, MA |
| High Light: | Industrial Hose conveying pump,KH -15 mini Industrial Hose pump,Industrial Hose conveying pump 10mm |
||
Application:
Application:
KH series hose pump is a new-type industrial hose pump with multifunction and multipurpose. Hose pump, absorbing the advanced foreign technology, has wide range of application and have great advantage to delivery high viscous, corrosive liquids or fluids with more impurities
Features:
1. No valve operation, no back flow, stable pumping flow, low fault rate.
2. Free exchange of suction inlet and discharge outlet. When the pump is blocked, reversing pump can discharge the obstruction.
3. High vacuum, strong self-suction capacity.
4. Convenient maintenance, less wearable parts (except extruded hose).
Data:
| model | rated output m3/h | rated pressure MPa | rated power kw | max.aggregate size mm | max.suction dist. m |
| KH-15 | 0.3 | 0.6 | 0.55 | 2 | 2 |
| KH-25 | 0.8-1.3 | 1.5 | 1.1/1.5 | 3 | 3 |
| KH-32 | 1.3-1.8 | 1.5 | 2.2 | 3 | 4 |
| KH-40 | 2.0-3.5 | 1.5 | 2.2/4 | 4 | 4 |
| KH-50 | 4.0-8.0 | 1.5 | 4/5.5 7.5 | 5 | 5 |
| KH-65 | 9.0-15.0 | 1.0 | 7.5/11 | 6 | 5 |
| KH-75 | 15.0-30.0 | 1.0 | 11/15 | 6 | 5 |
| KH-90 | 30.0-40.0 | 1.0 | 15/18 | 8 | 5 |
| KH-100 | 40.0-50.0 | 1.0 | 15/18 | 8 | 5 |
| KH-130 | 50.0-70.0 | 1.0 | 18/22 | 10 | 5 |
| KH-150 | 70.0-80.0 | 1.0 | 22/30 | 10 | 5 |
Spare parts:
Certification:
In July 2009, the company passed the ISO9001:2008 Quality Management System Certification.
In October 2010, the company was entitled as the “Henan Provincial High-tech Enterprise”.
In 2013, the new wet shotcrete technology was reward the second prize of Henan Provincial S&T Progress Award.
In December 2014, the brand “KEMING” was awarded the “Henan Provincial Famous Trademark”.
In October 2016, “KEMING” series products have been certified by CE Certification.
Why choose us:
Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. (the former Keming Mechanical and Electrical Department of Henan Coal Scientific Research Institute) is a holding subsidiary of Henan Coal Scientific Research Institute Co., Ltd.
Achievements: It has more than 20 national invention patents and utility model patents, and more than 10 identification of relevant departments. It has won 8 awards from coal associations and provincial departments, and won the Henan Provincial Science and Technology Progress Award.In 2014, “Keming” brand won the famous trademark of Henan Province. It has been awarded ISO9001 Quality Management System Certification, OHSAS 18001 Occupational Health and Safety Management System Certification, ISO14001 Environmental Management System Certification and CE Certification.
Service: mechanical and electrical products, chemical technology, the development and manufacture of mining products, technical research of energy conservation and environment protection technology, and relative consultation service.
Exhibition:
Bauma Shanghai 2018
FAQ:
1. Q:How to pay for this order?
A:Generally, TT, 30% deposit 70% before shipment; L/C at sight (high bank charge, not suggest, but acceptable);100% TT in advance (especially for small amount and spare parts etc.)
2. Q:How to place an order?
A:Both online order and offline order are acceptable.
3. Q:How about the package?
A:We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
4. Q:What is the lead time?
A:1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
5. Q:What should we do if there are some problems with the machine?
A:You can refer to the Operate Instruction or call our 24-hour service hotline. Also, our engineers are available to service overseas.
6. Q:Do i need technical skills to operate this machine?
A:Yes. Please read the Operation Instruction for some basic technical skills. And, we provide online and onsite technical training if necessary.
