| Certification: | CE, ISO | Product: | Hardness Material Concrete Batching Plant |
|---|---|---|---|
| Aggregate Kinds: | 2-4 | After-sales Service: | Video Aftersales Service |
| High Light: | Dry Hardness Grout Mixer Machine,KEMING Concrete Grout Mixer Machine,Grout Mixer Machine With Conveying System |
||
1. The sand, cinder and other raw materials are mixed and stirred, and finally made into concrete, which is put into construction and production as a wall material.
2. this is also determined by the superior characteristics of the concrete batching plant itself.
Hardness Material Concrete Batching Plant Feature:
1. The concrete mixing plant has good mixing performance, twin-shaft forced mixing main engines.
2. concrete mixing The station adopts the muffler device for the exhaust of the pneumatic system and the unloading equipment, which effectively reduces the noise pollution.
| Model | HZS25 | HZS35 | HZS50 |
| Mixing capacity | 25m3/h | 35m3/h | 50m3/h |
| Mixing Cycle Time | 72s | 72s | 72s |
| Aggregate amount | 2~3 | 3~4 | 4 |
| Total Installed Capacity | 60kW | 80kW | 111kW |
| Mixing model | JS500 | JS750 | JS1000 |
| Charging Capacity/Discharging Capacity | 800/500L | 1200/750L | 1600/1000L |
| Mixing time | 60s | 60s | 60s |
| Maximum particle size of aggregate (pebble/crushed stone) | <60/80mm | <60/80mm | <60/80mm |
| Discharge height | 2000/3800mm | 3800mm | 3800mm |
| Batching Machine model | PLD800 | PLD1200 | PLD1600 |
| Aggregate weighing range | 0-2000kg | 0-2000kg | 0-2000kg |
| Weighing accuracy | ±2% | ±2% | ±2% |
| Cement weighing range | 0-250kg | 0-400kg | 0-500kg |
| Weighing accuracy | ±1% | ±1% | ±1% |
| Water weighing range | 0-150kg | 0-250kg | 0-300kg |
| Weighing accuracy | ±1% | ±1% | ±1% |
| Admixtures weighing range | 0-25kg | 0-30kg | 0-50kg |
| Weighing accuracy | ±1% | ±1% | ±1% |
