| Product Name: | Full Hydraulic Remote Conveying Gunite Machine | Rated Working Pressure: | 0.2-0.5MPa |
|---|---|---|---|
| Rotor Speed: | 11r/min | Braking Method: | Hydraulic |
| Key Words: | PS5IL-J Full Hydraulic Remote Conveying Gunite Machine | ||
| High Light: | Remote Gunite Shotcrete Machine,Full Hydraulic Shotcrete Machine,11r/Min Hydraulic Shotcrete Machine |
||
1. The friction plate is pressed hydraulically.
2. The friction plate and rotating liner are automatically lubricated.
3. The hopper seat is automatically turned over, reducing the labor intensity of maintenance workers.
1. Accelerating agent vibration feeding, micro adjustment, to ensure accurate addition and reduce operating personnel.
2. The hydraulically driven crawler chassis travels automatically, which is convenient and fast to move.
3. According to the on-site wind pressure and air volume, the spray volume is steplessly adjusted.
|
raying part |
Capacity |
m3/h |
2~7 |
|
Delivery distance |
m |
>300 |
|
|
Max. aggregate size |
mm |
≤20 |
|
|
Delivery pipe ID. |
mm |
φ51 |
|
|
Air consumption |
m3/min |
≤8 |
|
|
Rotor speed |
r/min |
11 |
|
|
Dedusting part |
Capacity |
m³/h |
800 |
|
Pressure |
Pa |
2600 |
|
|
Walking mechanism |
Way of walking |
Crawler |
|
|
Walking speed |
km/h |
≤1.5 |
|
|
Gradeability |
|
≤15 |
|
|
Braking method |
|
Hydraulic |
|
|
Hydraulic system |
Motor Power |
kw |
18.5 |
|
Fuel tank capacity |
L |
200 |
|
|
Cooling method |
|
Air cooling |
