| Capacity: | 50L/min | Pressure: | 3Mpa |
|---|---|---|---|
| Motor: | 5.5KW | Option: | Diesel/Electric |
| High Light: | Cement Mortar Grout Pump,50L/Min Concrete Grouting Machine,Horizontal Mortar Grout Pump |
||
1. KBW-50 is horizontal single-cylinder reciprocating single-action piston pump.
2. Compact structure, well sealing performance, high stability and high pressure.
3. High quality pump parts, less wearing parts, long service life, low construction cost.
4. High pump efficiency, less noise and dust, environmental operation, easy maintenance.
1. KBW-50 piston pump is widely used for cement/mortar grouting in roads, bridges, dams, national defense, mines and other construction projects.
2. KBW-50 piston pump can be used to grout mortar in prestressed component engineering, vertical and horizontal conveying of mortar in building construction, cement grouting maintenance in sand land, blast furnace, cement pavement, highway and other projects.
|
Model
|
KBW-50 grouting pump
|
|
Capacity (L/min)
|
50
|
|
Cylinder number (piece)
|
1
|
|
Cylinder diameter (mm)
|
80
|
|
Piston stroke (mm)
|
90
|
|
Pressure (MPa)
|
3
|
|
Motor (KW)
|
7.5
|
|
Input speed (r/min)
|
1440
|
|
Suction hose ID. (mm)
|
51
|
|
Discharge hose ID. (mm)
|
32
|
|
Maximum suction height (m)
|
2
|
|
Triangle belt model
|
A1880 (3 grooves)
|
|
Dimensions (L x W x H) (mm)
|
1500×550×800
|
|
Weight (kg)
|
200
|
