Product Details:
Payment & Shipping Terms:
|
| Theory: | Pneumatic Pump | Capacity: | 10-50L/min |
|---|---|---|---|
| Pressure: | 3-30Mpa | Air Pressure: | 0.2-0.63MPa |
| High Light: | 50L/Min Injection Grouting Machine,Waterproof Pneumatic Grout Pump,Mixing Injection Grouting Machine |
||
1. Advanced structure, high output pressure, large output capacity, high efficiency.
2. The pump adopts compressed air to transmit pressure signal, which forms close automatic control system to ensure reliable performance.
3. Reversing mechanism has automatic positioning function by air pressure with no 'self-stop' phenomenon.
4. All cylinders work simultaneously to ensure even mixing and rated mixing ratio.
5. Suction valve and discharge valve can be quickly removed, easy maintenance.
6. Pneumatic transmission, strong anti-pollution ability, small size, light weight, easy movement.
1. The pump has single or double liquid grouting function.
2. It can be used to transport water, cement slurry, water glass or other less viscous and corrosive liquids.
3. It is widely used for water blocking and rock consolidation in coal mine, subways, hydro-power constructions, or for pre-grouting of working surface in deep well.
4. It can work in inflammable, explosive, strong radiative, dusty sites and other bad environments with changeable temperature.
|
Model
|
2ZBQ-20/4
|
2ZBQ-10/10
|
2ZBQ-30/3
|
2ZBQ-30/30
|
2ZBQ-50/19
|
|
Pressure(MPa)
|
4
|
10
|
3
|
30
|
19
|
|
Output(L/min)
|
20
|
10
|
30
|
30
|
50
|
|
Working air
pressure(MPa)
|
0.2-0.63
|
||||
|
Inlet dia.(mm)
|
25
|
||||
|
Outlet dia.(mm)
|
13
|
19
|
|||
