Tunnel Wet Shotcrete Machine 5.5m3/H Concrete Spraying Machine

China Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. certification
China Henan Coal Science Research Institute Keming Mechanical and Electrical Equipment Co. , Ltd. certification
I'm Online Chat Now

Tunnel Wet Shotcrete Machine 5.5m3/H Concrete Spraying Machine

Tunnel Wet Shotcrete Machine 5.5m3/H Concrete Spraying Machine
Tunnel Wet Shotcrete Machine 5.5m3/H Concrete Spraying Machine

Large Image :  Tunnel Wet Shotcrete Machine 5.5m3/H Concrete Spraying Machine

Product Details:
Place of Origin: CHINA
Brand Name: KEMING
Certification: CE,MA
Model Number: PC5I
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Export Wooden Case
Delivery Time: 10~20 Work Day
Payment Terms: L/C, T/T
Supply Ability: 100 Set/Per Month
Detailed Product Description
Capacity: 5~5.5m3/h Pressure: 0.6Mpa
Max Aggregate: 20mm Main Power: 5.5kW
Horz. Distance: 200m Vert. Distance: 40m
High Light:

Tunnel Wet Shotcrete Machine

,

5.5m3/H Concrete Spraying Machine

,

Culvert Concrete Spraying Machine

In Tunnel Wet Shotcrete Machine Concrete Spraying Machine For Sale

Shotcrete Machine Features:

1. PC5I Series Dry Shotcrete Machine have diesel engine (PZ-3D,PZ-5D,PZ-7D,PZ-9D), electric motor (PZ-3,PZ-5,PC5I,PZ-7,PZ-9) and pneumatic motor (PZ-3A,PZ-5A,PZ-7A,PZ-9A) etc.

2. PC5I Explosion proof Dry Shotcrete Machine is consisted of driving device, rotor assembly, air system, concrete spraying system, explosion-proof motor etc.

3. KPZ Series Dry Shotcrete Machine have advanced technology, rational structure, convenient operation, stable performance and long service life.

Shotcrete Machine Application:

1. PC5I Dry Concrete Shotcrete Machine can be used for dry or half wet concrete spray construction.

2. PC5I Dry Concrete Shotcrete Machine is widely used in the tunnel, culvert, subway, slope reinforcement, hydroelectric works, underground works and high-methane laneway of coal mine etc.

Shotcrete Machine Parameters:

Conveying dist. max.
100/30m
Suitable mixture ratio
cement/sand and gravel=1:3~5
Suitable water and cement ratio
>0.20
Aggregate size max.
φ20mm
Conveying pipe ID.
φ51mm
Operating pressure
0.5Mpa
Air consumption
8 m3/min
Material feeding height
1.1m
Rotor rotation speed
11r/min
Motor type
YBK2-132M-6
Motor power
5.5kw
Motor rotation rate
960r/min
Voltage
380v or 660v
Machine gauge
600mm (customized)
Dimensions(Length×width×height)
1520×820×1280mm
Total weight
800kg
