| Name: | Cement Grouting Pump | Powered: | Diesel Engine Powered |
|---|---|---|---|
| Capacity: | 32~150L/min | Pressure: | 1.8~7Mpa |
| Diesel Engine: | 18hp | Option: | Diesel/Electric |
| High Light: | cement injection grouting pump,cement grouting equipment |
||
1. KBW-150D mud slurry pump is horizontal triplex reciprocating single-acting piston pump.
2. Eight gear shift to adjust the flow, large output capacity, simple operation.
3. High quality pump parts, less energy consumption, less wearing parts, long service life.
4. Flexible manipulation, easy dismantlement and move.
1. KBW series mud slurry pump is widely used for grouting and mud jacking in engineering construction.
2. Mud slurry pump can be used to grout borehole flushing fluids (mud, clean water, saponification liquid), equipped with minor-caliber diamond drilling machine for drilling within 1500m, or used for middle-lower pressure cement grout.
|
Model
|
KLW-150D mud slurry pump
|
|
Pump type
|
Horizontal type
|
|
Function
|
Single acting
|
|
Cylinder number
|
3
|
|
Cylinder diameter
|
70mm
|
|
Piston stroke
|
70mm
|
|
Input speed
|
1500 r/min
|
|
Max. suction speed
|
2.5m
|
|
Suction pipe ID.
|
50mm
|
|
Discharge pipe ID.
|
32mm
|
|
Diesel Power
|
18 hp
|
|
Weight
|
750kg
|
|
Dimensions (L×W×H)
|
1770×1130×1220 mm
|
|
Stroke frequency, Output, Pressure
|
||||||||
|
Handle lever position
|
High 4
|
High 3
|
High 2
|
High 1
|
Low 4
|
Low 3
|
Low 2
|
Low 1
|
|
Stroke frequency
(min-1)
|
222
|
130
|
86
|
57
|
183
|
107
|
71
|
47
|
|
Output
(L/min)
|
150
|
90
|
58
|
38
|
125
|
72
|
47
|
32
|
|
Pressure
(MPa)
|
1.8
|
3.2
|
4.8
|
7.0
|
2.3
|
4.0
|
6.0
|
7.0
|
